OMS-4310-JK/6.0 DC-6GHz 4.3-10@Female/Male Coaxial RF Surge Arresters for Communication Base Station Antennas, 550w,IP67,20kA,CE,RoHs,FCC
Description:
OMRDON’s OMS-4310-JK/6.0 RF Surge Protector (a.k.a. Lightning Arrester), with 4.3-10 connectors, utilizes a GDT discharge design for almost instantaneous response to lightning surges, protecting the antenna while maintaining RF performance. This RF surge protector element is manufactured in a coaxial inline design with a wide operating frequency range.
Features:
- Surge current of 20KA
- Max Power 550W
- Frequency range from DC-6.0GHz
- Waterproof IP67 rated
- 4.3-10@female to male type connector
- VSWR <1.2, Low insertion loss
- DC Pass
- CE , RoHS , FCC
Applications:
- GNSS
- WiFi
- Radar stations
- Mobile communication
- Satellite communications
- Microwave stations
Technical Parameters:
| Name | Coaxial RF Surge Protector |
| Model | OMS-4310-JK/6.0 |
| Interface way | 4.3-10@female to male type connector |
| Nominal discharge current(In) | 10KA(8/20μs) |
| Maximum discharge current (Imax) | 20KA(8/20μs) |
| Response time (Ta) | ≤100ns |
| Max transmit power (Pt) | 550W |
| V.S.W.R | ≤1.2 |
| DC Spark-over Voltage(100V/s) | 90V/230V/350V |
| Maximum lmpulse Spark-over Voltage (1000V/s) | 600V/700V/800V |
| Impedance | 50Ω |
| Insertion Loss | ≤0.2dB |
| Frequency Range | DC-6.0GHZ |
| Insulation resistance | ≥5000 MΩ |
| material | Brass@Electroplate Ternary Alloy |
| lngress Protection Rating (IP) | Ip67 |
| Ground Resistance Ω / wire diameter | ≤4Ω /≥4mm2 |
| Work Environment | -40 ~ +85ºC,Altitude≤4km |
| Relative humidity (at room temperature conditions) | 30%~90% |
| Size | 54.8*22mm |
| Implementation of the standards | GBl8802.21/lEC61643-21/IEC60169-4 |
| Order No. | 8004341 |
Product Size & Simulated lightning shock test
OMS-4310/JK-6.0
